5"/6" LED Economy Down Light

    The DLE 56 down light is compatible with most 5" and 6" housings - with insulated, non-insulated and air-tight ceilings. Color temperature options range from 2700K to 5000K. The DLE 56 is dimmable to 10% with most dimmers. It features durable thermoplastic construction. The E26 medium screw-base Edison connector allows for easy retrofit of incandescent housings. An adjustable torsion spring, designed to fit 5" or 6" housing, allows for toolless installation. The DLE 56 is available with frame-in kits for both remodeling and new construction.
Spec Sheet
.ies file
  • Applications: Suitable for most commercial, industrial and institutional applications - retail, hospitality, office, residential
  • Lumen Output: 800-860 lm
  • Max Lumens Per Watt: 72
  • Predicted L70 Lifetime: 50,000 hours (reported)
  • Warranty: 5 year limited system warranty
  • Certifications: ETL listed for wet locations; Passes FCC Class B; RoHS Compliant
Buy Now
Request a Quote

Click to enlarge

DLE56schem DLE56schem
DLE 56 schematic
DLE56-1 DLE56-1
DLE 56
6ICRM 6ICRM
6ICRM schematic
6ICNCschem 6ICNCschem
6ICNC schematic
56ICNC and 56ICRM JPG 56ICNC and 56ICRM JPG
The 56ICNC new construction frame-in kit (left), and the 56ICRM remodeler frame-in kit
cETLus logo
Buy Now
Request a Quote
Note: Table scrolls horizontally
Catalog #
SizeLumensWattsLPWCRI / Color TempVoltages AvailablePredicted L70 Lifetime
DLE 56 MD 12 WB 8275" and 6" Housing800126780 CRI / 2700K120V50,000 hours (reported)
DLE 56 MD 12 WB 8305" and 6" Housing820126880 CRI / 3000K120V50,000 hours (reported)
DLE 56 MD 12 WB 8355" and 6" Housing830126980 CRI / 3500K120V50,000 hours (reported)
DLE 56 MD 12 WB 8405" and 6" Housing840127080 CRI / 4000K120V50,000 hours (reported)
DLE 56 MD 12 WB 8505" and 6" Housing860127280 CRI / 5000K120V50,000 hours (reported)
Catalog #
Equivalency*
DLE 56 MD 12 WB 82775W PAR-30 incand., 26W Triple T CFL
DLE 56 MD 12 WB 83075W PAR-30 incand., 26W Triple T CFL
DLE 56 MD 12 WB 83575W PAR-30 incand., 26W Triple T CFL
DLE 56 MD 12 WB 84075W PAR-30 incand., 26W Triple T CFL
DLE 56 MD 12 WB 85075W PAR-30 incand., 26W Triple T CFL
*NOTE: Fixture equivalencies are estimates only and should be confirmed by photometric analysis or sample install to ensure adequate light levels are achieved.
Catalog #
ImageSpec Sheet.ies files
DLE 56 MD 12 WB 827View Download Download
DLE 56 MD 12 WB 830View Download Contact Factory
DLE 56 MD 12 WB 835View Download Contact Factory
DLE 56 MD 12 WB 840View Download Contact Factory
DLE 56 MD 12 WB 850View Download Contact Factory
56ICNC and 56ICRM v2

Frame-in kits

    The DLE 56 is available with two types of frame-in kits. The 6ICNC is designed for new construction, while the 6ICRM is designed for remodel applications. Air tight construction in both kits provides reduced energy costs. See spec sheet for more details.
