5"/6" LED Gimbal Down Light

    The DLG 56 down light is compatible with most 5" and 6" housings - with insulated, non-insulated and air-tight ceilings. The slope ceiling gimbal is compatible with most 6" slope housings, and features a max tilt of 30 degrees. Color temperature options range from 2700K to 4000K. The DLG 56 is dimmable to 10% with most dimmers. It features durable thermoplastic construction. The E26 medium screw-base Edison connector allows for easy retrofit of incandescent housings. An adjustable torsion spring, designed to fit 5" or 6" housing, allows for toolless installation. The DLG 56 is available with frame-in kits for both remodeling and new construction.
Spec Sheet
.ies file
  • Applications: Suitable for most commercial, industrial and institutional applications - retail, hospitality, office, residential
  • Lumen Output: 975-1,080 lm
  • Max Lumens Per Watt: 75
  • Predicted L70 Lifetime: 50,000 hours (reported)
  • Warranty: 5 year limited system warranty
  • Certifications: ETL US and Canada listed for damp locations, passes FCC Class B
Buy Now
Request a Quote

Click to enlarge

DLG56jpg-3 DLG56jpg-3
DLG 56 schematic
6ICRM 6ICRM
6ICRM schematic
DLG56jpg-2 DLG56jpg-2
DLG 56
6ICNCschem 6ICNCschem
6ICNC schematic
DLG56jpg-1 DLG56jpg-1
DLG 56
56ICNC and 56ICRM JPG 56ICNC and 56ICRM JPG
The 56ICNC - 5"/6" IC new construction frame-in kit (left), and the 56ICRM - 5"/6" remodeler frame-in kit
cETLus logo
Buy Now
Request a Quote
Note: Table scrolls horizontally
Catalog #
SizeLumensWattsLPWCRI / Color TempVoltages AvailableWarrantyTitle 24, 2016Energy StarPredicted L70 Lifetime
DLG 56 MD 12 WB 8275" and 6" Housing975147080 CRI / 2700K120V5 yearsNoYes50,000 hours (reported)
DLG 56 MD 12 WB 8305" and 6" Housing975147080 CRI / 3000K120V5 yearsNoYes50,000 hours (reported)
DLG 56 MD 12 WB 8405" and 6" Housing1,050147080 CRI / 4000K120V5 yearsNoYes50,000 hours (reported)
DLG S 56 MD 12 WB 8275" and 6" Housing975137580 CRI / 2700K120V5 yearsNoYes50,000 hours (reported)
DLG S 56 MD 12 WB 8405" and 6" Housing975137580 CRI / 4000K120V5 yearsNoYes50,000 hours (reported)
Catalog #
Equivalency*
DLG 56 MD 12 WB 82775W PAR-30 incand., 26W Triple T CFL
DLG 56 MD 12 WB 83075W PAR-30 incand., 26W Triple T CFL
DLG 56 MD 12 WB 84075W PAR-30 incand., 26W Triple T CFL
DLG S 56 MD 12 WB 82775W PAR-30 incand., 26W Triple T CFL
DLG S 56 MD 12 WB 84075W PAR-30 incand., 26W Triple T CFL
*NOTE: Fixture equivalencies are estimates only and should be confirmed by photometric analysis or sample install to ensure adequate light levels are achieved.
Catalog #
ImageSpec Sheet.ies files
DLG 56 MD 12 WB 827View Download Download
DLG 56 MD 12 WB 830View Download Contact Factory
DLG 56 MD 12 WB 840View Download Contact Factory
DLG S 56 MD 12 WB 827View Download Contact Factory
DLG S 56 MD 12 WB 840View Download Contact Factory
56ICNC and 56ICRM v2

Frame-in kits

    The DLG 56 is available with two types of frame-in kits. The 6ICNC is designed for new construction, while the 6ICRM is designed for remodel applications. Air tight construction in both kits provides reduced energy costs. See spec sheet for more details.
