LED Flood/Wall Sconce

    The highly efficient FWS is functional as an LED wall sconce or flood light. It comes with two mounts for added flexibility - a knuckle mount for ground, wall or eave mounting, and a detachable wall mounting plate that allows for simple installation when making electrical connections. The attractive, modern styling of the FWS makes it a welcome addition to many commercial or residential exterior applications. There are three lumen output packages to choose from. Photocells are optional for the HI ("high") lumen output package.
  • Applications: Suitable for commercial or residential exterior ground, wall or eave mount applications: entryways, perimeter/security, landscape lighting
  • Lumen Output: From 1,510 lm to 5,470 lm
  • Max Lumens Per Watt: 111.9
  • Predicted L70 Lifetime: >50,000 hrs
  • Warranty: 5 year limited system warranty
  • Certifications: UL listed for wet locations. IP65-rated

Click to enlarge

FWS HI2 FWS HI2
FWS HI as a flood
FWS HI3 FWS HI3
FWS HI as a flood
FWS HI4 FWS HI4
FWS HI as a flood and a wall sconce
FWS HI5 FWS HI5
FWS HI as a wall sconce
FWS LW1 FWS LW1
FWS LW as a wall sconce
FWS schematic FWS schematic
FWS schematic
FWS HI1 FWS HI1
FWS HI as a wall sconce
FWS LW3 FWS LW3
FWS LW as a flood
FWS LW4 FWS LW4
FWS LW as a wall sconce
FWS LW5 FWS LW5
FWS LW as a wall sconce and a flood
FWS MD1 FWS MD1
FWS MD as a wall sconce
FWS MD2 FWS MD2
FWS MD as a flood
FWS MD4 FWS MD4
FWS MD as a flood
FWS MD5 FWS MD5
FWS MD as a wall sconce
FWS MD6 FWS MD6
FWS MD as a wall sconce and a flood
FWS LW2 FWS LW2
FWS LW as a flood
PBLU 3
Note: Table scrolls horizontally
Catalog #
LumensWattsLPWShieldingOpticCRI / Color TempVoltages AvailableWarrantyPredicted L70 Lifetime
FWS LW F UV FP 7401,51015.1100Frosted polycarbonateFlood70+ CRI / 4000K120-277V5 years>50,000 hrs
FWS MD F UV FP 7403,16828.3111.9Frosted polycarbonateFlood70+ CRI / 4000K120-277V5 years>50,000 hrs
FWS HI F UV FP 7405,47049.3111Frosted polycarbonateFlood70+ CRI / 4000K120-277V5 years>50,000 hrs
Catalog #
Equivalency*
FWS LW F UV FP 74039W MH
FWS MD F UV FP 74070W MH
FWS HI F UV FP 740100W MH
Catalog #
ImageSpec Sheet.ies & .pdf files
FWS LW F UV FP 740View Download Download
FWS MD F UV FP 740View Download Download
FWS HI F UV FP 740View Download Download
FWS JPG blue bg

Versatile and durable

    The housing of the FWS is constructed of die cast aluminum. It is coated in a fade, weather and abrasion resistant textured polyester powder coat finish. The lens is impact resistant and UV-stabilized polycarbonate.
