LED Hazardous Location Luminaire

The HZL4 is a Class 1, Division 2 hazardous location rated LED luminaire. The HZL4 can be ceiling- or wall-mounted. The vandal resistant polycarbonate lens is available in clear or frosted variations. The housing and top-frame is constructed of heavy duty die-cast aluminum. A powdercoat finish covers a chromate conversion coating.

  • Applications: Suitable for most interior or exterior Class 1, Division 2 hazardous locations: industrial, manufacturing
  • Lumen Output: 13,000-19,700 lumens
  • Max Lumens Per Watt: 130.1
  • Predicted L70 Lifetime: >100,000 hours (calculated)
  • Warranty: 5 year limited system warranty
  • Certifications: ETL listed for hazardous locations per UL844; Class 1, Division 2 Groups A, B, C, D;  T4 Temperature Rating; IP66
https://www.lumenfocus.com/wp-content/uploads/2018/04/HZL4-1.jpg
HZL4
https://www.lumenfocus.com/wp-content/uploads/2018/04/AB-mounting.jpg
The stainless steel adjustable bracket (AB)
https://www.lumenfocus.com/wp-content/uploads/2018/04/HZL4-YK-screen-capture.jpg
The stainless steel yoke mount (YK)
https://www.lumenfocus.com/wp-content/uploads/2018/04/HZL4-schematic.jpg
HZL4 schematic

HZL4 Performance Chart

Catalog #
LumensWattsLPWShieldingLumen OutputCRI / Color TempVoltages AvailableWarrantyPredicted L70 Lifetime
HZL 4 LW UV CP 840
Photometry Files | Image
15,636126122.7Clear PolycarbonateLow80 CRI / 4000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
HZL 4 LW UV CP 850
Photometry Files | Image
16,287126127.8Clear PolycarbonateLow80 CRI / 5000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
HZL 4 LW UV FP 840
Photometry Files | Image
13,172126105.3Frosted PolycarbonateLow80 CRI / 4000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
HZL 4 LW UV FP 850
Photometry Files | Image
13,720126109.7Frosted PolycarbonateLow80 CRI / 5000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
HZL 4 MD UV CP 840
Photometry Files | Image
18,982152124.9Clear PolycarbonateMedium80 CRI / 4000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
HZL 4 MD UV CP 850
Photometry Files | Image
19,773152130.1Clear PolycarbonateMedium80 CRI / 5000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
HZL 4 MD UV FP 840
Photometry Files | Image
15,930152105.4Frosted PolycarbonateMedium80 CRI / 4000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
HZL 4 MD UV FP 850
Photometry Files | Image
16,594152109.7Frosted PolycarbonateMedium80 CRI / 5000K120-277V, 347V, 480V5 years>100,000 hrs (calculated)
*NOTE: Fixture equivalencies are estimates only and should be confirmed by photometric analysis or sample install to ensure adequate light levels are achieved.
