LED Vaporproof Light

    The VPJE is a high performance LED vaporproof luminaire with wall mount or ceiling mount options. The VPJE is shielded against dust, moisture and vapor from entering the luminaire. It features a built-in junction box with 5" mounting flanges and 1/2" NPT for threaded conduit on the sides. It has a shot blasted aluminum finish in gray.
Spec Sheet
High Res Images
.ies files
.pdf files
  • Applications: Suitable for most indoor or outdoor applications where moisture or debris is an issue
  • Lumen Output: 1,420 lm
  • Max Lumens Per Watt: 106
  • Predicted L70 Lifetime: >50,000 hours
  • Warranty: 5 year limited system warranty
  • Certifications: UL listed for wet locations
Buy Now
Request a Quote

Click to enlarge

VPJEWM-jpg1 VPJEWM-jpg1
VPJE wall mount
VPJECM-jpg2 VPJECM-jpg2
VPJE ceiling mount
VPJECM-jpg1 VPJECM-jpg1
VPJE ceiling mount
VPJE schematic VPJE schematic
VPJE schematic
VPJEWM-jpg2 VPJEWM-jpg2
VPJE wall mount
PBLU 3
Buy Now
Request a Quote
Note: Table scrolls horizontally
Catalog #
LumensWattsLPWShieldingCRI / Color TempVoltages AvailableWarrantyPredicted L70 Lifetime
VPJE HI UV FP 7401,42013.4106Frosted polycarbonate70 CRI / 4000K120-277V5 years>50,000 hrs
Catalog #
Equivalency*
VPJE HI UV FP 74025W CFL or 100W incandescent
*NOTE: Fixture equivalencies are estimates only and should be confirmed by photometric analysis or sample install to ensure adequate light levels are achieved.
Catalog #
ImageSpec Sheet.ies & .pdf files
VPJE HI UV FP 740View Download Download
VPJECM-jpg1 green bg

Durable construction

    The VPJE features a die-cast aluminum back plate, junction box and heat sink. The frosted globe is thermal impact-resistant polycarbonate. The die-cast threaded cage guard is secured with stainless steel hardware.
