LED Architectural Wall Cylinder

    The WCP features sleek architectural styling and high performance LED technology. With two light sources - one up and one down - the WCP is suitable for wall grazing and perimeter/security lighting. The cylinder is constructed of extruded aluminum. The end caps are UV-stabilized polycarbonate. The dark bronze polyester powdercoat finish is chip and fade resistant.
  • Applications: Suitable for commercial or residential exterior wall mount applications: wall grazing, perimeter/security lighting
  • Lumen Output: 1,312
  • Max Lumens Per Watt: 65.3
  • Predicted L70 Lifetime: >50,000 hours
  • Warranty: 5 year limited system warranty
  • Certifications: UL listed for wet locations. IP65 rated

Click to enlarge

WCP schematic WCP schematic
WCP schematic
PBLU 3
Note: Table scrolls horizontally
Catalog #
LumensWattsLPWOpticCRI / Color TempVoltages AvailableWarrantyPredicted L70 Lifetime
WCP MD NF 12 8301,31220.165.3Narrow Flood80 CRI / 3000K120V5 years>50,000 hrs
Catalog #
ImageSpec Sheet.ies & .pdf files
WCP MD NF 12 830View Download Download
WCP outdoor

Easy to install

    The WCP features a detachable mounting plate with hanging wire for simple hands-free installation when making electrical connections.
