LED Wall Pack

    The WPM is a high performance LED wall pack that features an integral photocell and a 0-10V dimming driver standard. It is suitable for many exterior wall mount applications. The housing is covered with a chip and fade resistant powder coat finish in dark bronze.
  • Applications: Suitable for commercial or residential exterior wall mount applications: entryways, perimeter/security lighting
  • Lumen Output: 2,468 lumens
  • Max Lumens Per Watt: 119.8
  • Predicted L70 Lifetime: >50,000 hours
  • Warranty: 5 year limited system warranty
  • Certifications: UL listed for wet locations. IP65 rated

Click to enlarge

WPM schematic WPM schematic
WPM schematic
PBLU 3
Note: Table scrolls horizontally
Catalog #
LumensWattsLPWOpticCRI / Color TempVoltages AvailableWarrantyPredicted L70 Lifetime
WPM HI F UV CPP 7402,46820.6119.8Forward70 CRI / 4000K120-277V5 years>50,000 hrs
Catalog #
Equivalency*
WPM HI F UV CPP 74050W MH
*NOTE: Fixture equivalencies are estimates only and should be confirmed by photometric analysis or sample install to ensure adequate light levels are achieved.
Catalog #
ImageSpec Sheet.ies & .pdf files
WPM HI F UV CPP 740View Download Download
WPM-1jpg Greenbg

Construction

    The WPM features a die-cast aluminum rear housing with an impact-resistant and UV-stabilized polycarbonate front housing. The prismatic lens is also made of impact resistant and UV-stabilized polycarbonate.
